National Instruments 9485 Measurement System 8-channel solid-state relay digital output module

1 image: Click to enlarge

National Instruments · CompactDAQ / CompactRIO

NI 9485 Measurement System

The NI 9485 is an eight-channel C Series solid-state relay output module for switching externally powered loads. It supports switching up to 60 VDC or 30 Vrms.

ManufacturerNational Instruments

Model9485 Measurement System

Part Number779600-01 · 779600-02

Product Type8-channel solid-state relay digital output module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: 9485 Measurement System

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Outputs8 solid-state relay channels

Switching voltage60 VDC or 30 Vrms maximum

Switching current750 mA/channel across all 8 channels; 1.2 A/channel for up to 4 channels

PlatformNI C Series

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The NI 9485 provides relay switching rather than analog signal acquisition. Its isolated outputs connect to industrial loads such as actuators and DC devices.

NI documents use in CompactDAQ and CompactRIO chassis. Select the chassis and software configuration for the intended control environment.

Normally open solid-state relays.
Channel-to-channel isolation.
Screw-terminal connections for field wiring.

Verified specifications

Technical data

Verified product specifications.

Digital output channels	8 channels
Relay type	Normally open solid-state relay
Maximum DC switching voltage	60 VDC
Maximum AC switching voltage	30 Vrms
Maximum switching current, all channels	0.75 per channel A
Maximum switching current, up to four channels	1.2 per channel A
Switching rate at 90% duty cycle	1 operation/s
Typical relay open time	0.5 ms
Typical relay close time	9.0 ms
Continuous channel-to-channel isolation	60 VDC, Measurement Category I, up to 5,000 m
Operating temperature	-40 to 70 °C
Front connection	Screw terminal

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

Host chassis platforms

C Series

Module family and chassis interface

NI 9485

Relay output module

Check load voltage, channel current, and switching duty cycle against the NI documentation before wiring.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9485 Product PageOfficial Product Page · ni.com

Open →

NI 9485 DatasheetDatasheet And Specifications · download.ni.com

Open →

NI 9485 Getting Started GuideGetting Started Guide · docs-be.ni.com

Open →

Controlling a Solenoid with the NI 9485 or NI-9482Technical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the NI 9485 a PXI Express analog acquisition module?

No. NI identifies it as a C Series relay output module, not a PXI Express analog acquisition device.

Which manufacturer part numbers belong to the NI 9485?

NI lists 779600-01 as the standard version and 779600-02 as the conformal-coated version. The supplied catalog record does not identify which version this item represents.

Can the NI 9485 control a solenoid?

NI documents solenoid control using an external power supply wired in series with the load and relay. The load must remain within the module's switching limits.
