NI 9411

The NI 9411 is a six-channel C Series digital input module supporting differential or single-ended signals. In a CompactDAQ chassis, it supports correlated digital measurements, triggering and synchronization.

ManufacturerNational Instruments

ModelNI 9411

Part Number779005-01 · 779005-02

Product TypeC Series digital input module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9411

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Inputs6 digital input channels

Signal configurationDifferential or single-ended

Input delay500 ns maximum

Signal connection15-pin DSUB

Digital inputs6 channels

Input signalingDifferential or single-ended

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The NI 9411 interfaces industrial switches, transducers and other digital devices to a modular acquisition system. It is an input module, not a standalone embedded controller.

Its inputs share a common reference rather than individual channel isolation. Differential and single-ended wiring use different logic thresholds; consult the connection guide before attaching a device.

The NI 9411 interfaces industrial switches, transducers, and other digital devices with a modular acquisition system. Its six input channels accept differential or single-ended signals; it has no digital output channels.

In CompactDAQ systems, the module supports correlated digital acquisition and counter connectivity. NI also documents CompactRIO counter applications using digital input modules such as the NI 9411, with implementation dependent on the system's programming interface.

Accepts differential and single-ended digital signals.
Supports CompactDAQ counter connections.
Enables correlated measurements, triggering and synchronization in CompactDAQ.
Provides channel-to-earth isolation, with no channel-to-channel isolation.
Six digital input channels supporting differential or single-ended signaling.
Correlated measurements, triggering, and synchronization when installed in a CompactDAQ chassis.
Input mode is determined by signal wiring rather than a software configuration setting.
Channels share a common ground; there is no channel-to-channel isolation.

Verified specifications

Technical data

Verified product specifications.

Digital input channels	6 channels
Input type	Differential or single-ended
Maximum input delay	500 ns
Differential logic high	0.3 to 24 V
Differential logic low	-24 to -0.3 V
Differential common-mode voltage	-7 to 12 V
Single-ended logic high	2 to 24 V
Single-ended logic low	0 to 0.8 V
Input impedance	8.4 kΩ
Channel-to-channel isolation	None
Continuous channel-to-earth isolation	30 V RMS / 42.4 V peak / 60 V DC
Operating temperature	-40 to 70 °C
Input delay time	500 maximum ns
Differential input high range	0.3 to 24 V
Differential input low range	-24 to -0.3 V
Single-ended input high range	2 to 24 V
Single-ended input low range	0 to 0.8 V
Signal connector	15-pin DSUB

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ

Modular acquisition platform

NI 9411

C Series digital input module

System integration

CompactDAQ supports correlated digital measurements with this module.

Check the selected chassis and software support before integration; follow the NI 9411 wiring guide.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9411 Product PageProduct Page · ni.com

Open →

NI-9411 SpecificationsSpecifications · ni.com

Open →

NI 9411 DatasheetDatasheet · download.ni.com

Open →

NI 9411 Getting Started GuideConnection And Safety Guide · download.ni.com

Open →

NI-9411 Product PageProduct Page · ni.com

Open →

NI-9411 Dimensional DrawingsDimensional Drawings And CAD · ni.com

Open →

NI-9411 Dimensional DrawingsTechnical resource

Open →

Using the NI 9411 Inputs as Differential or Single-EndedTechnical resource

Open →

Using a Digital Module for Counter Input on the CompactRIOTechnical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the NI 9411 an embedded controller?

No. It is a six-channel C Series digital input module used within a modular system.

Can I connect differential or single-ended devices?

Yes. The getting started guide provides connection diagrams for both configurations, including encoder wiring.

Does the 500 ns specification describe a sample rate?

NI specifies 500 ns as the maximum input delay. It should not be treated as a system acquisition sample rate.

Does the NI 9411 provide digital outputs?

No. It has six digital input channels and no digital output channels.

How is differential or single-ended operation selected?

Selection is made through wiring, not software. Differential operation uses DIa and DIb. For single-ended operation, wire the positive input and leave the negative input floating, as described by NI.

Does 500 ns describe the complete system acquisition rate?

No. NI specifies 500 ns as the maximum input delay. It describes signal propagation through the input circuitry, rather than establishing the complete chassis-to-software acquisition rate.
