The NI 9265 is a four-channel C Series analog current output module with a 0–20 mA range, 16-bit resolution and simultaneous updates up to 100 kS/s per channel.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The NI 9265 provides current outputs for interfacing with industrial current-driven actuators. Its built-in open-loop detection generates a software interrupt when an open loop is detected, and its outputs start at zero current.
The module fits CompactDAQ and CompactRIO systems and requires an external power supply. NI offers screw-terminal and spring-terminal versions; the exact connector variant for this catalog record has not been established.
Verified product specifications.
| Analog output channels | 4 channels |
|---|---|
| Output current range | 0–20 mA |
| DAC resolution | 16 bits |
| Maximum analog update rate | 100 kS/s/channel |
| External supply voltage | 9–36 VDC |
| Maximum compliance voltage | 12 VDC |
| Maximum load | 600 Ω |
| Channel-to-channel isolation | None |
| Operating temperature | -40 to 70; subject to chassis environmental requirements °C |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Host platforms
C Series current output module
Designed for CompactDAQ and CompactRIO chassis; verify the intended chassis and software combination using NI's compatibility documentation.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
No. It is a four-channel current output module with a specified 0–20 mA range, not a ±10 V voltage output module.
Yes. The module requires a 9–36 VDC external supply.
Built-in open-loop detection generates a software interrupt.
