The NI 9264 provides 16 simultaneous ±10 V analog outputs with 16-bit resolution and update rates up to 25 kS/s per channel.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The NI 9264 adds high-density voltage outputs to CompactDAQ and CompactRIO systems. Its 16-channel format conserves chassis slots for other measurement types.
NI offers DSUB and spring-terminal versions. Confirm the installed connector and exact part number before selecting wiring accessories.
Verified product specifications.
| Analog output channels | 16 channels |
|---|---|
| DAC resolution | 16 bits |
| Nominal output range | ±10 V |
| Maximum simultaneous update rate | 25 kS/s/ch |
| Connector options | 36-position spring terminal or 37-pin DSUB; variant dependent |
| Operating temperature | -40 to 70 °C |
| Channel-to-channel isolation | None |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Supported system platforms
C Series voltage output module
Designed for NI CompactDAQ and CompactRIO systems; verify the specific chassis and software combination against NI's compatibility guidance.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
It has 16 voltage output channels, with a dedicated DAC for each channel.
No. NI specifies simultaneous updates at up to 25 kS/s per channel.
The supplied record does not identify a connector variant. The NI 9264 family includes spring-terminal and DSUB versions.
