National Instruments NI 9239 C Series Voltage Input Module
1 image: Click to enlarge
National Instruments · CompactDAQ / CompactRIO

NI 9239

The NI 9239 is a four-channel C Series voltage input module with differential inputs, 24-bit resolution and simultaneous sampling at 50 kS/s per channel. It provides a ±10 V input range and channel-to-channel isolation.

ManufacturerNational Instruments
ModelNI 9239
Part Number779593-01
Product TypeC Series Voltage Input Module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9239

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Analog inputs4 differential channels
Resolution24-bit
Sample rate50 kS/s per channel
Input range±10 V
Input couplingDC
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The NI 9239 performs isolated differential voltage measurements. Its floating input front end helps reduce measurement errors caused by ground loops.

Designed for CompactDAQ and CompactRIO systems, each channel has an independent ADC. Analog and digital filtering reject out-of-band signals.

  • Simultaneous acquisition across all four inputs.
  • Channel-to-channel isolation.
  • Delta-sigma conversion with analog prefiltering.
  • Anti-alias filtering.
Verified specifications

Technical data

Verified product specifications.

Analog input channels4 differential channels
ADC resolution24 bits
Sampling modeSimultaneous
Nominal input range±10 V
Data rates with internal timebase1.613 to 50; discrete rates kS/s/ch
Input couplingDC
Input impedance1 MΩ
Operating temperature-40 to 70; subject to chassis requirements °C
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

System platforms

NI 9239

C Series voltage acquisition module

779593-01

Screw-terminal variant

Confirm the installed connector variant before applying isolation limits; screw-terminal and BNC versions have different ratings.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9239 Product PageProduct Page · ni.com
Open →
NI 9239 DatasheetDatasheet · download.ni.com
Open →
NI-9239 Dimensional DrawingsDimensional Drawings And CAD Models · ni.com
Open →
NI-9239 Mechanical Drawings and CAD ModelsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Does the NI 9239 sample its channels simultaneously?

Yes. All four channels use independent ADCs for simultaneous sampling.

Does the NI 9239 offer selectable AC coupling?

No. NI specifies DC input coupling.

Which connector corresponds to part number 779593-01?

NI identifies 779593-01 as the screw-terminal version. Confirm the part number on the physical module.
