National Instruments NI 9237 C Series Strain/Bridge Input Module
1 image: Click to enlarge
National Instruments · CompactDAQ and CompactRIO

NI 9237

The NI 9237 is a four-channel C Series strain/bridge input module with simultaneous 24-bit acquisition at up to 50 kS/s per channel. It provides signal conditioning and excitation for bridge-based sensors in CompactDAQ and CompactRIO systems.

ManufacturerNational Instruments
ModelNI 9237
Part Number779521-01
Product TypeC Series Strain/Bridge Input Module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9237

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Analog inputs4 simultaneous bridge channels
Maximum sample rate50 kS/s per channel
Resolution24-bit
Input range±25 mV/V
779521-01 connectionFour RJ50 sensor connectors
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

Designed for strain and load measurements, the NI 9237 powers and acquires signals from up to four bridge-based sensors simultaneously. Its independent channel ADCs eliminate interchannel phase delay.

NI offers RJ50 and D-SUB versions of this model. The catalog-associated part number 779521-01 identifies the RJ50 version; connection accessories should be selected for the actual module variant.

  • Built-in excitation for half-bridge and full-bridge sensors.
  • Remote sensing and shunt calibration functions help address bridge wiring resistance errors.
  • Analog and digital filtering reject out-of-band signals.
  • Quarter-bridge measurements are supported with appropriate external bridge-completion accessories.
Verified specifications

Technical data

Verified product specifications.

Analog input channels4 channels
ADC resolution24 bit
Maximum sampling rate per channel50 kS/s
Sampling architectureSimultaneous
Bridge input range±25 mV/V
Operating temperature-40 to 70 °C
Isolation architectureBank isolated from earth ground; channels are not isolated from each other
Channel-to-earth ground isolation60 VDC
Front connection for 779521-014 RJ50 connectors
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

System platforms

C Series

Modular I/O family and interface

NI 9237

Strain/bridge analog input module

Do not insert RJ45 Ethernet connectors into the RJ50 version; NI warns that they can damage the connector.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9237 Official Product PageProduct Page · ni.com
Open →
NI 9237 DatasheetDatasheet · download.ni.com
Open →
NI-9237 Dimensional DrawingsDimensional Drawings And CAD Models · ni.com
Open →
C Series RJ45/RJ50 Cable and Accessory GuideTechnical resource
Open →
NI Guidance on Ethernet Cables and NI-9237 ConnectorsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the NI 9237 a 16-channel voltage input module?

No. It has four simultaneous bridge input channels, 24-bit resolution, a ±25 mV/V input range, and a maximum rate of 50 kS/s per channel.

Can the RJ50 version measure quarter-bridge strain gauges?

Yes, with suitable external completion accessories. NI lists the NI 9944 for 120 Ω quarter bridges and the NI 9945 for 350 Ω quarter bridges.

Can I use a standard RJ45 Ethernet cable?

No. NI warns that RJ45 connectors can damage the NI 9237 RJ50 connector. Use the appropriate RJ50 cable.

Ask SOHO AssistantProduct & compatibility help
