NI 9234

The NI 9234 is a four-channel C Series sound and vibration input module with simultaneous 24-bit acquisition, a ±5 V input range and 51.2 kS/s/channel sampling using its internal timebase.

ManufacturerNational Instruments

ModelNI 9234

Part Number779680-01

Product TypeC Series Sound and Vibration Input Module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9234

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Inputs4 simultaneously sampled analog channels

Resolution24-bit delta-sigma ADC

Input range±5 V

SamplingUp to 51.2 kS/s/channel with internal timebase

Signal conditioningSoftware-selectable AC/DC coupling and IEPE excitation

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The NI 9234 measures IEPE and non-IEPE sensor signals, including accelerometers, tachometers and proximity probes. Its channels include anti-aliasing filters that automatically adjust to the sampling rate.

As a C Series module, it fits supported CompactDAQ and CompactRIO configurations. Check the selected chassis, software versions and acquisition mode against NI's compatibility documentation.

Simultaneous sampling across all four input channels.
Software-selectable AC or DC input coupling.
IEPE excitation can be enabled or disabled in software.
Supports IEEE 1451.4 TEDS Class I sensors.

Verified specifications

Technical data

Verified product specifications.

Analog input channels	4 channels
ADC resolution	24 bits
Sampling mode	Simultaneous
Input range	±5 V
Data rate range, internal timebase	1.652–51.2 kS/s/channel
Data rate range, external timebase	0.391–52.734 kS/s/channel
Input coupling	AC/DC, software-selectable
IEPE excitation current	2.0 minimum; 2.1 typical mA
AC coupling cutoff, −3 dB	0.5 Hz
Operating temperature	−40 to 70 °C
Front connections, 779680-01	4 BNC connectors
