National Instruments NI 9232 C Series Sound and Vibration Input Module

1 image: Click to enlarge

National Instruments · CompactDAQ / CompactRIO

NI 9232

The NI 9232 is a three-channel C Series sound and vibration input module with simultaneous 24-bit acquisition at up to 102.4 kS/s per channel. It supports ±30 V signals, selectable AC/DC coupling and IEPE sensor excitation.

ManufacturerNational Instruments

ModelNI 9232

Part Number782000-01

Product TypeC Series Sound and Vibration Input Module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9232

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Analog inputs3 simultaneous channels

Resolution24-bit

Maximum sample rate102.4 kS/s/channel using internal timebase

Nominal input range±30 V

Sensor conditioningSelectable IEPE excitation and AC/DC coupling

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

Designed for industrial dynamic-signal measurements, the NI 9232 operates in NI CompactDAQ and CompactRIO systems. Its three channels acquire simultaneously rather than sharing a multiplexed conversion path.

The module accepts IEPE and non-IEPE sensors, including accelerometers, tachometers and proximity probes. Built-in anti-aliasing filters track the selected sample rate; compatible NI software provides condition-monitoring functions such as frequency analysis and order tracking.

Software-selectable AC or DC coupling.
IEPE excitation can be enabled or disabled for AC-coupled channels.
Smart TEDS sensor support with IEEE 1451.4 Class I compatibility.
IEPE open-circuit and short-circuit detection.

Verified specifications

Technical data

Verified product specifications.

Analog input channels	3 channels
ADC resolution	24 bits
ADC architecture	Delta-sigma with analog prefiltering
Sampling mode	Simultaneous
Maximum sample rate, internal timebase	102.4 kS/s/channel
Nominal input range	±30 V
Input coupling	Software-selectable AC/DC
IEPE excitation settings	0 or 4 mA
TEDS support	IEEE 1451.4 Class I
Channel-to-channel isolation	None
Continuous channel-to-earth isolation	60 VDC, Measurement Category I

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

Supported system platforms

NI 9232

C Series dynamic-signal input module

System integration

Verify the specific chassis, controller and software combination using NI's hardware compatibility information.

Channel-to-earth isolation does not provide channel-to-channel isolation. Follow the datasheet's input and common-mode limits.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI 9232 DatasheetDatasheet · download.ni.com

Open →

NI-9232 Product Information and Variant ComparisonManufacturer Product Page · ni.com

Open →

NI-9232 Dimensional DrawingsDimensional Drawings And CAD Models · ni.com

Open →

C Series Module and CompactDAQ or CompactRIO Hardware CompatibilityTechnical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is 102.4 kS/s shared across the three channels?

No. The NI 9232 samples all three channels simultaneously at up to 102.4 kS/s per channel using its internal master timebase.

Can it measure sensors without IEPE excitation?

Yes. The module supports non-IEPE sensors and provides selectable AC/DC coupling. IEPE excitation can be switched off for AC-coupled measurements.

Which connector version is associated with 782000-01?

NI identifies 782000-01 as the screw-terminal NI 9232. Other NI 9232 part numbers identify different connector or coating variants, so confirm the unit's label before selecting wiring accessories.
