National Instruments NI 9206 C Series Voltage Input Module
1 image: Click to enlarge
National Instruments · CompactDAQ and CompactRIO

NI 9206

The NI 9206 is a 16-bit C Series voltage input module with 32 single-ended or 16 differential channels and 250 kS/s aggregate sampling. NI identifies fuel-cell and battery-stack monitoring as key applications.

ManufacturerNational Instruments
ModelNI 9206
Part Number779526-01
Product TypeC Series Voltage Input Module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9206

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Channels32 single-ended or 16 differential
Resolution16-bit
Sampling250 kS/s aggregate; multiplexed
Voltage ranges±200 mV, ±1 V, ±5 V, ±10 V
ConnectionSpring terminal
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

Four per-channel programmable ranges support voltage measurements from ±200 mV to ±10 V. Channel-to-earth isolation permits monitoring cell banks elevated above earth potential without making the individual inputs high-voltage measurement channels.

Inputs share a common reference and multiplexed ADC; acquisition is not simultaneous. The module integrates into CompactDAQ or CompactRIO systems.

  • Selectable single-ended and differential input configurations.
  • Individually programmable voltage ranges.
  • Channel-to-earth isolation rated 600 VDC in the U.S. and 400 VDC in Europe, Measurement Category I.
Verified specifications

Technical data

Verified product specifications.

Analog input channels32 single-ended / 16 differential channels
ADC resolution16 bits
Maximum aggregate sample rate250 in CompactDAQ and CompactRIO kS/s
Nominal input ranges±0.2, ±1, ±5, ±10 V
Simultaneous samplingNo
Front connectionSpring terminal
Continuous channel-to-earth isolation600 U.S.; 400 Europe; Measurement Category I VDC
Channel-to-channel isolationNone
Maximum input working voltageEach channel within ±10.4 of COM, including signal and common mode V
Operating temperature-40 to 70 °C
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

Host platforms for C Series modules

NI 9206

Voltage input module

System selection

Check NI's hardware and software compatibility tables for the intended chassis and programming mode.

Earth isolation does not increase the input-to-COM measurement range. Do not use for Category II, III or IV measurements.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9206 Product PageProduct Page · ni.com
Open →
NI 9206 DatasheetDatasheet · download.ni.com
Open →
NI-9206 Dimensional DrawingsDrawings And CAD Models · ni.com
Open →
C Series Hardware Compatibility with LabVIEWTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Does the NI 9206 sample all channels simultaneously?

No. It uses multiplexed acquisition, and 250 kS/s is the aggregate rate, not a per-channel rate.

Does this model use a DSUB connector?

No. NI specifies spring-terminal connectivity for the NI 9206.

What is the NI part number?

NI lists 779526-01 for the NI 9206.
