National Instruments DAQCARD-5102 High-speed digitizer
1 image: Click to enlarge
National Instruments · PCMCIA

DAQCARD-5102

The National Instruments DAQCard-5102 is a two-channel PCMCIA digitizer with 8-bit resolution and simultaneous sampling at up to 20 MS/s per channel.

ManufacturerNational Instruments
ModelDAQCARD-5102
Product TypeHigh-speed digitizer
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: DAQCARD-5102

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
InterfacePCMCIA Type II
Inputs2 single-ended, simultaneously sampled
Resolution8 bits
Real-time sampling20 MS/s per channel maximum
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

This is the PCMCIA member of the NI 5102 digitizer family, distinct from the PCI, PXI and USB versions.

  • Software-selectable AC or DC input coupling.
  • Four input ranges without probe attenuation.
  • Analog triggering from CH 0, CH 1 or TRIG.
Verified specifications

Technical data

Verified product specifications.

Small-signal bandwidth15, typical, −3 dB MHz
Input ranges without probe attenuation±5 V, ±1 V, ±0.25 V, ±50 mV
Input impedance1 MΩ ±1% in parallel with 40 pF ±10 pF
Onboard FIFO memory663000 per channel samples
Maximum waveform buffer663000 per channel samples
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PCMCIA

Host interface

DAQCARD-5102

Digitizer

Confirm host-slot and driver support before integration.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI 5102 Specifications, 371143D-01Specifications · download.ni.com
Open →
NI 5102 SpecificationsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Does the DAQCard-5102 sample both channels simultaneously?

Yes. Both single-ended channels support simultaneous sampling.

Is this a PXI module?

No. This record identifies the PCMCIA version.
