National Instruments cDAQ-9137 Eight-slot embedded data acquisition controller
1 image: Click to enlarge
National Instruments · CompactDAQ

cDAQ-9137

The NI cDAQ-9137 is an eight-slot CompactDAQ controller with an embedded 1.91 GHz quad-core Intel Atom processor. It combines with C Series modules for analog and digital measurement and local data logging.

ManufacturerNational Instruments
ModelcDAQ-9137
Product TypeEight-slot embedded data acquisition controller
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: cDAQ-9137

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Module capacity8 C Series slots
ProcessorIntel Atom E3845, quad-core, 1.91 GHz
Ethernet2 ports, 10/100/1000 Mbps
DC input9–30 VDC
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The cDAQ-9137 integrates an embedded computer and an eight-slot C Series chassis. Measurement signals can be logged locally to internal storage or an SD card.

NI documents Windows Embedded Standard 7 and LabVIEW Real-Time variants. Confirm the installed operating system before selecting software or planning deployment.

  • Embedded processing for locally executed acquisition applications.
  • Modular analog and digital I/O using C Series modules.
  • USB 2.0 host and device interfaces, RS-232, and mini DisplayPort.
Verified specifications

Technical data

Verified product specifications.

Module slots8 slots
CPUIntel Atom E3845; 4 cores; 1.91 GHz
System memory2 GB DDR3L
Internal SSD32 GB
Ethernet ports2; 10/100/1000 Mbps, auto-negotiated
Power input9–30 VDC
Maximum power consumption46; fully populated system under NI's specified maximum-load conditions W
Operating temperature-20 to 55; mounting requirements apply °C
Dimensions, unloaded328.8 × 88.1 × 118.6 mm
Weight, unloaded2.5 kg
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ

Modular data acquisition platform

cDAQ-9137

Eight-slot embedded controller for C Series I/O

Compatibility

Uses C Series I/O modules; verify individual module and software requirements in NI documentation.

Confirm the operating-system variant and module-specific requirements before configuring the system.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI cDAQ-9137 SpecificationsSpecifications · download.ni.com
Open →
NI cDAQ-9132/9133/9134/9135/9136/9137 User ManualUser Manual · docs-be.ni.com
Open →
NI cDAQ-9137 Safety, Environmental, and Regulatory InformationSafety Guide · download.ni.com
Open →
cDAQ-9137 Dimensional DrawingsDrawings And CAD Models · ni.com
Open →
cDAQ-9137 Product CertificationsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
cDAQ-9136View product →
Related model
cDAQ-9133View product →

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the cDAQ-9137 an I/O module or a controller?

It is an embedded CompactDAQ controller with eight slots for C Series I/O modules, not an individual I/O module.

Does it have a fixed analog resolution or channel count?

No. Measurement specifications depend on the installed C Series modules; consult each module's documentation.

Which operating-system variant is this catalog unit?

The supplied record does not establish the installed operating system. NI documents both Windows Embedded Standard 7 and Real-Time variants.
