National Instruments PXI-8430/16 16-port RS-232 serial interface module
1 image: Click to enlarge
National Instruments · PXI

PXI-8430/16

The National Instruments PXI-8430/16 is a 16-port, nonisolated RS-232 serial interface module for PXI systems. It supports baud rates up to 1 Mbaud and provides serial I/O through two 68-pin VHDCI connectors.

ManufacturerNational Instruments
ModelPXI-8430/16
Product Type16-port RS-232 serial interface module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PXI-8430/16

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
PlatformPXI
Serial ports16 RS-232 ports
IsolationNonisolated
Maximum baud rate1 Mbaud
I/O connectorsTwo 68-pin VHDCI connectors
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The PXI-8430/16 provides 16 RS-232 ports in a 3U PXI module. NI identifies this model separately from the similarly named PXIe-8430/16, which uses the PXI Express interface.

NI lists the PXI-8430/16 among the hardware supported by NI-Serial 21.3. Consult the driver readme when selecting the software environment for an existing system.

  • 16 RS-232 serial ports on a PXI interface.
  • Configurable baud rates from 2 baud to 1 Mbaud.
  • Two 68-pin VHDCI connectors for serial I/O.
  • Nonisolated interface design.
Verified specifications

Technical data

Verified product specifications.

Bus interfacePXI
Serial port count16 ports
Serial protocolRS-232
IsolationNone
Maximum baud rate1000 kbaud
I/O connectors2 × 68-pin VHDCI
Form factor3U
Dimensions100 × 160 mm
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PXI

Module bus platform

PXI-8430/16

16-port RS-232 serial interface

Driver reference

Listed as supported hardware in the NI-Serial 21.3 readme.

Distinguish PXI-8430/16 from PXIe-8430/16 when checking the host slot and software configuration.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI Serial Hardware Specifications and Features GuideSpecifications And Hardware Guide · docs-be.ni.com
Open →
NI-Serial 21.3 ReadmeDriver Readme And Supported Hardware · ni.com
Open →
PXI-8430/16 hardware specifications: see printed page 35Technical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

Electronic Test and Instrumentation

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Does the PXI-8430/16 support RS-485 or RS-422?

NI specifies RS-232 for this model, not RS-485 or RS-422.

Are the serial ports isolated?

No. NI lists the PXI-8430/16 as nonisolated.

What connectors does this module use?

The module has two 68-pin VHDCI I/O connectors.

Is this the same model as the PXIe-8430/16?

No. NI lists PXI-8430/16 under PXI interfaces and PXIe-8430/16 under PXI Express interfaces.
