National Instruments · PXI

PXI-4351

The NI PXI-4351 is a high-precision temperature and DC voltage measurement module in the NI 435x family.

ManufacturerNational Instruments

ModelPXI-4351

Product TypeTemperature and voltage meter

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PXI-4351

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Analog inputs16 differential or 14 thermocouple

ADC24-bit sigma-delta

Excitation25 µA and 1 mA

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

Supports thermocouples, RTDs, thermistors, resistance measurements, and current measurements using external shunt resistors.

Low-leakage construction.
Analog and digital filtering.
Programmable open-thermocouple detection and ground-referencing.

Verified specifications

Technical data

Verified product specifications.

Analog inputs	16 differential or 14 thermocouple
ADC resolution	24 bits
Voltage ranges	±0.625, ±1.25, ±2.5, ±3.75, ±7.5, ±15 V
Bandwidth	20 Hz

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PXI

Platform

PXI-4351

Measurement module

Check chassis, driver, and operating-system requirements before integration.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI 435x User ManualUser Manual And Specifications · docs-be.ni.com

Open →

NI 435x operation, wiring, and specificationsTechnical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

PXI Platform

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Can it measure resistance?

Yes, using its built-in precision current sources.

Is multichannel reading rate specified per channel?

Divide the multichannel reading rate by the number of scanned channels.
