The National Instruments PXI-2565 is a 16-channel SPST power relay module with non-latching electromechanical relays. It occupies two slots in a 3U PXI/cPCI system.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The PXI-2565 belongs to NI's general-purpose relay module range. NI's connection guide identifies a 16-pin terminal plug kit for wiring this model.
Verified product specifications.
| Relay type | Electromechanical, non-latching |
|---|---|
| Maximum switching voltage | 125 V DC; 250 V AC |
| Maximum switching current | 5 A at 30 V DC; 7 A at 250 V AC, resistive per channel |
| Maximum switching power per channel | 150 W; 1750 VA |
| Minimum switch load | 10 mA, 5 V DC |
| I/O connector | 16 × 2 minicombicon header |
| Form factor | 3U, two-slot PXI/cPCI |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
