National Instruments PR68-68F Unshielded DAQ ribbon cable

1 image: Click to enlarge

National Instruments · NI DAQCard

PR68-68F

The National Instruments PR68-68F is an unshielded ribbon cable for documented NI DAQCard configurations. NI identifies part number 183646-0R1 in its portable Engine Knock Detector Start-Up Kit configuration.

ManufacturerNational Instruments

ModelPR68-68F

Part Number183646-0R1

Product TypeUnshielded DAQ ribbon cable

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PR68-68F

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Cable constructionRibbon cable

ShieldingUnshielded

Documented part number183646-0R1

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The PR68-68F is a DAQ connection accessory, not a data acquisition card. NI documents its use with the DAQCard-AI-16XE-50 in a portable engine-knock measurement configuration.

NI also lists the PR68-68F as an unshielded cable option between legacy 68-pin HSDIO DAQCard devices and SCB-68 or SCB-68A terminal blocks. That configuration supports direct feedthrough only; terminal-block DIP switches must be configured accordingly.

Ribbon-cable construction documented by NI.
Unshielded cable option in NI's SCB-68 and SCB-68A accessory guide.
Recommended with the DAQCard-AI-16XE-50 in NI's portable Engine Knock Detector Start-Up Kit configuration.
