National Instruments NI 9223 C Series Voltage Input Module
1 image: Click to enlarge
National Instruments · CompactDAQ and CompactRIO

NI 9223

The NI 9223 is a four-channel differential voltage input module with 16-bit resolution and simultaneous sampling up to 1 MS/s per channel. It belongs to the NI C Series for CompactDAQ and CompactRIO systems.

ManufacturerNational Instruments
ModelNI 9223
Part Number781398-01
Product TypeC Series Voltage Input Module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9223

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Inputs4 differential voltage channels
Nominal input range±10 V
Resolution16 bits
SamplingSimultaneous, up to 1 MS/s per channel
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The NI 9223 acquires voltage signals rather than generating analog outputs. Each channel has an independent signal path and ADC, allowing all four inputs to be sampled simultaneously.

NI identifies ballistics, impact, and blast wave testing as relevant applications. The module can also run at its maximum per-channel sample rate alongside a slower-sampling module in a mixed-measurement system.

  • Independent ADCs preserve the sampling rate on each channel rather than sharing an aggregate rate.
  • Differential inputs support voltage measurements across four channels.
  • 60 VDC CAT I channel-to-channel isolation.
Verified specifications

Technical data

Verified product specifications.

Analog input channels4 differential
Nominal voltage input range±10 V
ADC resolution16 bits
Maximum sample rate per channel1 MS/s
Sampling modeSimultaneous; independent ADC per channel
Front connection for part number 781398-014 screw-terminal connectors
Operating temperature-40 to 70 °C
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

Host platforms

NI 9223

C Series voltage acquisition module

Compatibility

NI documents the NI 9223 for CompactDAQ and CompactRIO chassis.

Confirm the exact part number and front connector before selecting signal wiring.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI 9223 DatasheetDatasheet · download.ni.com
Open →
NI-9223 Official Product PageProduct Page · ni.com
Open →
C Series Specifications Explained: Simultaneous Sampling and Sample RateTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the NI 9223 an analog output module?

No. It is a four-channel differential voltage input module for acquiring signals.

Is 1 MS/s shared among the four channels?

No. The maximum rate is 1 MS/s per channel. Each channel has its own ADC for simultaneous acquisition.

Which connector corresponds to part number 781398-01?

NI lists 781398-01 as the screw-terminal version. Other NI 9223 part numbers use different front connections.
