National Instruments cDAQ-9191 Single-slot Wi-Fi and Ethernet data acquisition chassis
1 image: Click to enlarge
National Instruments · CompactDAQ

cDAQ-9191

The NI cDAQ-9191 is a single-slot CompactDAQ chassis that connects a supported C Series I/O module to an external host through Wi-Fi or Ethernet. It is designed for small, remote, or distributed sensor measurement systems.

ManufacturerNational Instruments
ModelcDAQ-9191
Part Number781497-01
Product TypeSingle-slot Wi-Fi and Ethernet data acquisition chassis
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: cDAQ-9191

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Module capacity1 C Series I/O module
Wireless interfaceIEEE 802.11b/g
Wired interface10/100 Mbps Ethernet
Power input9–30 VDC
Counters/timers4 onboard, 32-bit
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The cDAQ-9191 provides chassis timing, synchronization, and data transfer between an installed C Series module and a host computer. Its single-slot design suits measurement points that do not require a multi-slot chassis.

Measurement types, channel counts, and signal capabilities depend on the selected C Series module. The chassis itself is not a fixed-channel analog or digital I/O module; NI-DAQmx provides the software interface for measurement applications.

  • Single C Series module slot for a compact measurement configuration.
  • Wireless or wired communication with an external host computer.
  • Four general-purpose counters/timers, accessed through an installed hardware-timed digital C Series module.
  • Wireless signal-strength LEDs assist with connection assessment.
Verified specifications

Technical data

Verified product specifications.

Module slots1 slot
Ethernet communication rate10/100, auto-negotiated Mbps
Wireless radio modesIEEE 802.11b and 802.11g
DC input voltage9–30 VDC
Maximum power consumption6; includes maximum 1 W module load under the manufacturer's stated conditions W
Operating temperature0–55; horizontal mounting to a metal panel or surface required at 45–55 °C °C
Dimensions, unloaded without antenna202.7 × 88.7 × 33.6 mm
Weight, unloaded without antenna481 g
Ingress protectionIP30; indoor use only
General-purpose counters/timers4
Counter/timer resolution32 bits
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ

Modular data acquisition platform

cDAQ-9191

Single-slot network chassis

Software

NI-DAQmx supports measurement application development; verify the selected driver, firmware, and operating-system combination.

Confirm module and software support before integration. Wireless throughput depends on the module, acquisition configuration, and RF environment.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI cDAQ-9191 Product and Support PageProduct Support Page · ni.com
Open →
NI cDAQ-9191 SpecificationsSpecifications PDF · download.ni.com
Open →
Archived: NI Wi-Fi DAQ Frequently Asked QuestionsTechnical FAQ · ni.com
Open →
cDAQ-9191 Firmware and Additional DriversTechnical resource
Open →
Firmware Information for NI CompactDAQ Network ChassisTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the cDAQ-9191 an eight-slot I/O module?

No. It is a single-slot CompactDAQ chassis that holds one supported C Series I/O module.

Does the cDAQ-9191 have a fixed channel count or analog resolution?

No. These measurement characteristics depend on the installed C Series module rather than a fixed chassis-wide channel count or converter resolution.

Can it communicate over Ethernet instead of Wi-Fi?

Yes. The cDAQ-9191 supports 10/100 Mbps Ethernet as well as IEEE 802.11b/g wireless communication.

How are the onboard counters accessed?

The four 32-bit counters/timers are accessed through an installed hardware-timed digital C Series module.
