National Instruments NI 9263 C Series voltage output module
1 image: Click to enlarge
National Instruments · CompactDAQ and CompactRIO

NI 9263

The NI 9263 is a four-channel C Series analog voltage output module with simultaneous updates at 100 kS/s per channel and a nominal ±10 V output range.

ManufacturerNational Instruments
ModelNI 9263
Part Number779012-01 · 783740-01
Product TypeC Series voltage output module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9263

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Outputs4 analog voltage channels
Resolution16-bit
Update rate100 kS/s per channel, simultaneous
Nominal output range±10 V
Current drive±1 mA maximum per channel
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The NI 9263 provides voltage outputs in CompactDAQ and CompactRIO systems. Each channel uses its own digital-to-analog converter.

NI offers screw-terminal and spring-terminal versions. Confirm the installed version before selecting wiring accessories; the catalog record does not identify a specific connection variant.

  • Simultaneous updating of four voltage outputs.
  • 16-bit digital-to-analog conversion.
  • Overvoltage and short-circuit protection on each channel.
  • Channel-to-earth ground double isolation barrier.
Verified specifications

Technical data

Verified product specifications.

Analog output channels4 channels
DAC resolution16 bits
Simultaneous update rate100 kS/s/channel
Nominal output voltage range±10 V
Maximum current drive per channel±1 mA
Output impedance2 Ω
Overvoltage protection±30 V
Channel-to-channel isolationNone
Operating temperature-40 to 70; observe chassis environmental requirements °C
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

Host platforms for C Series modules

NI 9263

Analog voltage output module

Connection variants

Screw-terminal and spring-terminal versions

Confirm the module connection variant, chassis support and software requirements before integration.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9263 Official Product PageProduct Page · ni.com
Open →
NI 9263 DatasheetDatasheet · download.ni.com
Open →
NI-9263 Getting StartedGetting-started Guide · ni.com
Open →
NI 9263/9264 Devices Don't Output Up to 10 VoltsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the 100 kS/s update rate shared across all four channels?

No. NI specifies 100 kS/s per channel with simultaneous updates.

Does the NI 9263 provide voltage or current outputs?

It provides voltage outputs with a nominal ±10 V range. Maximum current drive is ±1 mA per channel.

Which terminal version does this catalog record identify?

The supplied record identifies the NI 9263 model only. NI lists screw-terminal part number 779012-01 and spring-terminal part number 783740-01; the specific unit's version remains unconfirmed.
